■Features
This noise clip securely fastens wires (cables and wiring) and simultaneously grounds conductive noise to the housing, etc. Use it for shielding purposes.
-The material is nylon, so it does not retain heat.
- The clamping part is nearly perfectly round, so it will not damage the wire.
- A wide range of sizes are available to fit your cable perfectly.
■ Recruitment history
・For noise suppression in broadcasting equipment, video equipment, medical equipment, etc.
■Sales
・This product can be purchased individually.
◆Click here for the catalogue
| Material | 66 nylon + electroless nickel plating |
| standard | UL 94 V-0 (Nylon) |
| Applicable screws | M4 |

| Model number | Fixed inner diameter D | L | W | T | D1 |
| DN-3S | 4.5 | 9.5 | 9.3 | 0.9 | 4.3 |
| DN-4S | 6.2 | 10.4 | |||
| DN-5S | 7.5 | 11.5 | 1.0 | ||
| DN-6S | 10.0 | 12.8 | |||
| DN-8S | 12.2 | 15.4 | |||
| DN-10S | 14.5 | 16.6 |
Unit: mm
*Sales of the DN-2S have been discontinued due to size consolidation.
| Model number | Inner diameter when fixed (mm) | List price | 10 pieces | 100 pieces |
| DN-3S | 4.5 | 160 | 138 | 99 |
| DN-4S | 6.2 | 160 | 138 | 99 |
| DN-5S | 7.5 | 160 | 138 | 99 |
| DN-6S | 10.0 | 160 | 138 | 99 |
| DN-8S | 12.2 | 168 | 140 |
100 |
| DN-10S | 14.5 | 168 | 140 | 100 |
*Price revision: November 6, 2015
